99% removal of entrained droplets and particles larger than 10 microns. Enter the lowest operating pressure and the maximum steam weight flow. For air and other gases, use the gas-liquid sizing tool.
Chosen size
8 in
Standard and receiver
Standard required
6.35 in
All styles except receiver
Receiver required
7.90 in
Up to 90% liquid load
Sizing-flow ratio for the chosen size. Actual ΔP uses (weight flow ÷ maximum capacity)² × rated ΔP. Inlet moisture is 2,000 lb/hr (5.0% of weight flow). Type 31L / L1 is the smallest style that covers that liquid load in this body.
Rates are a percent of the chosen size’s maximum capacity, used to size the drain trap and to confirm the separator can take the entrained liquid. GPS is an approximate slug rate. Removal is 99% of droplets larger than 10 microns when the body is large enough for that style.
| Design | % of capacity | lb/hr | GPH | GPM | GPS | This duty |
|---|---|---|---|---|---|---|
| Type 31L / L131L, 36L · Horizontal flow or vertical down-flow · Slugs: No | 5% | 3,119 | 374 | 6.23 | 0.104 | Covers load |
| Type 32L / L232L, 34L, 37L, EH · Vertical up-flow | 10% | 6,239 | 748 | 12.47 | 0.208 | Covers load |
| L-Series31L/S, 33L, 35L, LS, DTL · Combined horizontal and vertical paths · Slugs: Yes | 20% | 12,477 | 1,496 | 24.93 | 0.416 | Covers load |
| Type TT, TT, DT, ST · Horizontal body, vertical vortex · Slugs: Yes | 40% | 24,954 | 2,992 | 49.87 | 0.831 | Covers load |
| Type TSTS · Elongated Type T with hold-up volume · Slugs: Yes | 60% | 37,432 | 4,488 | 74.80 | 1.247 | Covers load |
| ReceiverR · Two-stage vortex, compact footprint · Slugs: Yes | 90% | 56,147 | 6,732 | 112.21 | 1.870 | Covers load |
Same pressure, every standard inlet. Use it to trade body size against actual differential pressure.
| Size | Max lb/hr | % of max | Actual ΔP | Fit |
|---|---|---|---|---|
| 4 in | 15,824 | 240.9% | 21.90 PSI | Too small |
| 5 in | 24,610 | 154.9% | 9.05 PSI | Too small |
| 6 in | 35,304 | 108.0% | 4.40 PSI | Too small |
| 8 inChosen | 62,386 | 61.1% | 1.41 PSI | Standard and receiver |
| 10 in | 97,021 | 39.3% | 0.58 PSI | Standard and receiver |
| 12 in | 139,173 | 27.4% | 0.28 PSI | Standard and receiver |
| 14 in | 188,811 | 20.2% | 0.15 PSI | Standard and receiver |
| 16 in | 245,910 | 15.5% | 0.09 PSI | Standard and receiver |
The mixture is spun so droplets and particles larger than 10 microns reach the wall. Dry steam leaves through the discharge. A containment plate keeps the vortex from re-entraining the pooled condensate. There are no moving parts and nothing to service.
Efficiency holds at the low velocities of startup and shutdown. These centrifugal designs are not limited to a narrow flow band. Size them on the minimum pressure and the maximum mass flow.
Cast iron, carbon steel, stainless, and the alloys common in chemical plants and refineries. Type T cast-iron bodies are used on steam, and the ST includes an integral float drain trap. Traps still belong on the piping; the separator removes droplets that a trap on the main never sees.
Turbine inlets, jacketed vessels, autoclaves, heating coils, vulcanizing, corrugators, and steam onto a process or a food surface. Horizontal, vertical-down, and vertical-up paths are covered by different models — match the orientation in the removal table.
Same factors as the steam sheet. Liquid LPM, LPH, and GPM convert as water mass flow, not as steam volume. PSI results can be sent straight into the pressure or flow fields.
